Airflow UV purification device
Airlia compact dual
Dual-Technology Disinfection for Air and Surfaces
Combines UV air disinfection with ozone surface treatment for comprehensive environmental hygiene.
Helps reduce airborne microorganisms while also supporting odor control.
Characteristics
- Dual UV and ozone disinfection technology
- Air disinfection and deodorization
- Surface treatment with controlled ozone output
- Three-speed airflow control
- Safe enclosed UV design
- Smart maintenance reminder system
- Compact, energy-efficient operation
- Long-life, low-maintenance components
Applications
- Hospitals & Healthcare Facilities
- Food Processing Plants
- Restaurants & Commercial Kitchens
- Schools & Cafeterias
- Electronics Manufacturing Facilities
- Cleanrooms
- Hotels & Hospitality Facilities
- Sports & Fitness Centers
- Offices & Commercial Buildings
Airlia compact dual: specifications
Coverage guide (for Unit selection)
1 unit: up to 66 m³
*Reference capacity based on reducing Bacillus subtilis to 1/100 after 12 hours under controlled test conditions. Actual results may vary.
- Model
- FZSTZ15101GL1
- Production type
- Standard Product
- Application
- Disinfection of airborne bacteria and surfaces
- Sterilization method
- UV light + ozon + fan ventilation system
- Voltage
- 100V
- Frequency
- 50/60Hz
- Power consumption
- 41W (50Hz), 37W (60Hz): During high power operation
- Airflow
- (High: 50Hz) 1.1m³/min, (High: 60Hz) 1.2m³/min, (Mid) 0.6m³/min, (Low) 0.4m³/min
- Noise level
- (High) 53dB, (Mid) 40dB, (Low) 32dB: 50Hz
- Compatible lamps
- GL15 x 1
- Material
- Steel
- Weight
- 11.0kg
- Power cord length
- Approx. 1.7 m (with Plug)
- Safety features
- Automatic shut-off when cover is opened, Ozone generator control interlock
*Noise Level Reference (Approximate): 60 dB (inside a moving car), 50 dB (quiet office environment)
Compatible lamps: specifications
- Model
- GL15
- Lamp output
- 15W
- Tube diameter
- ø25.5mm
- Total length
- 436mm
- Emission length
- 348mm
- Lamp current
- 0.3A
- Lamp life
- 8000h
- Cap
- Pin type
Performance Test Results
Kitasato Research Center for Environmental Science (Japan) (Report number: 北生発 2021_0704)
Test Description
- Test chamber volume: 25 m³
- Test organism: Escherichia coli phage MS2 (NBRC 102619)
- Airborne test organisms were dispersed inside the chamber and sampled at predetermined time intervals.
- Counts of the test organism were measured and compared over time during operation of the unit.
Airborne test organism reduction over time
- * Operating mode: Airflow: High; Ozone: None
- * The vertical axis is a logarithmic display.
Ex)
Vertical axis 5=10⁵=100000
Vertical axis 2=10²=100
Handling / Usage Precautions
- This product is not a medical device.
- The actual disinfection or purification effects can change depending on the condition or the use of the room.
- The UV (disinfection) lamp contains a very small amount of mercury. Please be careful when handling the glass, and dispose according to each communities' collection categorization rules.
- Please note that the device's fan will emit a sound, so be careful when using it in quiet areas such as libraries and museums.
- Never look directly or indirectly at the lamp while it is illuminated. Avoid exposure to reflected UV light as well. Failure to do so may result in eye pain or visual impairment.
- Do not expose skin directly or indirectly to UV radiation. Doing so may cause skin inflammation or irritation.
- If you experience ozone odor, headaches, throat or nasal irritation, or any unusual physical symptoms, stop using the product immediately and ventilate the area. Consult a physician if symptoms persist.
- Do not remain near the air outlet during ozone generation. Prolonged direct inhalation of ozone may be harmful to health.
- Always switch off the power before replacing the lamp or performing maintenance. Failure to do so may result in electric shock, eye pain, visual impairment, or skin inflammation.
- If smoke, an unusual odor, or any abnormal condition occurs, immediately switch off the power and contact your installer or the nearest sales office.
- Dust and dirt on the lamp or the reflector surfaces will reduce disinfection performance. Clean them with a soft cloth lightly moistened with a diluted neutral detergent, then wipe dry with a clean cloth to remove any detergent residue.
- Do not modify or disassemble the unit. Doing so may result in fire or electric shock.
- Do not wash the unit with water during maintenance or cleaning. Doing so may result in fire or electric shock.
- This product is designed for indoor use only. Do not use it outdoors or in locations exposed to water or excessive moisture. Failure to do so may result in electric shock due to insulation failure.
- Do not insert metal objects or flammable materials into any openings of the unit. Doing so may result in fire or electric shock.
